Optical fiber is an ideal light transmission tool. It can be combined with various detection equipment such as spectrometer, power meter, temperature detector for optical analysis. It is common used for the light in and out of the intergrating sphere for high sensitivity measurement. Core diameter, length, connector and core number can be customized.
Quartz optical fiber adopts quartz material as the optical core layer and fluorine-doped quartz material as the optical skin layer, covered with a resin coating layer to ensure the strength of the optical fiber, and can be coated with an outer sheath layer if necessary. The use of fluorine-doped quartz material as the optical skin makes the optical fiber transmissoin spectrum range wider and can transmit high-power optical energy. It is the main fiber type we use for optical applications.
Near-infrared optimized quartz fiber
The refractive index of the near-infrared optimized silica fiber series is a step distribution, and the core is made of low-hydroxy quartz material. It has excellent transmission performance in the VIS-NIR band, which can meet the application of high-power laser transmission, and has advantages in infrared spectroscopy applications. This series of products includes two types of acrylic resin coating and polyimide resin coating, and can provide step-shaped silica fibers with different core diameters, cladding diameters and numerical apertures according to customer needs.
Features
Application
* Optical application test, research measurement, etc.
* Medical light detection equipment
* Industrial silicon wafers, liquids, spectral detection, etc.
* Video security monitoring
* Industrial Control, Factory Automation
* Automotive and Aircraft
*laser transmission,
* Laser welding,
* laser cutting,
* laser coupling,
* Laser diode pigtails,
* spectral detection,
* illumination,
* sensor,
* data communication,
* LAN
* Cable TV and other fields
Features
* Good coupling, high light transmittance* good fatigue resistance
* Large core diameter energy fiber, a variety of specifications optional
* Diversified selection of connectors, special customization
* Optical fiber 600um optional
* The wavelength range of 400nm-2500nm can be selected
