Model Number: WT-L45
Insertion loss: Less than 0.2dB
Return loss: more than 50dB
Diameter: 0.9/2.0/3.0mm
Features:
Low insertion loss and back reflection loss;
Ferrule end surface predomed;
Boots in a variety of colors;
100% interferometer measurement;
Various fiber cable option; G652D, G657A, G657B3, OM1, OM2, OM3, OM4 option;
| Fast Connector Specification | |||
| Mode | SM | MM | |
| Polish | UPC | APC | PC |
| Insertion Loss | Typical ≤0.2dB Maximum ≤0.3dB | ≤0.25dB | |
| Return Loss | ≥50dB | ≥65dB | ≥35dB |
| Interchangeability | ≤0.2dB | ||
| Repeatability | ≤0.1dB | ||
| Durability | ≤0.2dB (500 times mating) | ||
| Tensile Strengh | ≥50N | ||
| Temperature | ≤0.2dB (-40+85 sustain 100 hours) | ||
| Humidity | ≤0.2dB (+25+65 93 R.H.100 hours) | ||
