Model name: 2.0mm Indoor Breakout Fiber Optic Cable
Fiber Type: YOFC, corning or customized fiber
Application: fiber optic patchcord production and FTTH system
Application:
1. Adopted to indoor distribution.
2. As pigtail of communication equipment.
3. Suitable for communication equipment servrd.
4. Can be installed conveniently and perated simply.
Characteristics:
1. High strength kevlar yarn member.
2. Steel armored flexble tube increase the cable is twist resistance.
Technical Parameters
| Cable Count | Out sheath Diameter | Weight | Minimum allowable Tensile Strength(N) | Minimum allowable Crush Load(N/100mm) | Minimum Bending Radius(MM) | Storage temperature | |||
| (MM) | (KG) | Short term | Long term | Short term | Long term | Short term | Long term | ℃ | |
| 4 | 7.5 | 45 | 200 | 400 | 300 | 1000 | 20D | 10D | -20 to +60 |
| 6 | 8.5 | 60 | 250 | 600 | 300 | 1000 | 20D | 10D | |
| 8 | 10.0 | 91 | 300 | 800 | 300 | 1000 | 20D | 10D | |
| 12 | 12.5 | 145 | 400 | 1000 | 300 | 1000 | 20D | 10D | |
